3.2inch 13.5MHZ HF RFID Reader Industrial PDA Handheld Rfid Reader Writer Used In GPS
|
Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
Detil Deskripsi produk
| Cahaya Tinggi: | rfid reader writer,Handheld RFID Readers |
||
|---|---|---|---|
3.2inch 13.5MHZ HF RFID Reader Industrial PDA Handheld Rfid Reader Writer Used In GPS
Description :
Mainly use Marvell PXA310(624MHZ) CPU , Connecting the Internet by GPRS ,EDGE ,or 3g WCDMA /EVDO ;
Support Windows mobile / Windows CE system , and at the same time , some products can provide Android system ;
On the basis of BASE plate added three optional function module :
1.1D/2D barcode scanner function module ;
2.LF/HF RFID Reader function module ;
3.DGPS /Printer/ZIGBEE function module ;
specificaton :
| Hardware | ||
| CPU | Marvell PXA310(624MHz)/can update to 806MHz | |
| RF Band |
GSM Quad-band 850/900/1800/1900MHz, GPRS, EDGE |
|
| Display |
3.2inch TFT LCD display (320 x 240) 65k color/touch panel/Transflective screen |
|
| Form Factor | Bar type classical Pocket PC,Industrial appearance | |
| Memory | Flash ROM | 256MB |
| RAM | 128MB DDR | |
| Extend Slot | Micro SD 16G (SDHC) | |
| GPS Solution | Ublox The 5th Generation | |
| Wire Transmission | USB 2.0 Full Speed, charging/sync | |
| Bluetooth |
Bluetooth SIG version 2.0 compliant; Supported profiles: headset, hands-free, object push, serial port, dial-up network |
|
| WiFi | WiFi (802.11 b/g) | |
| RFID | read and write (13.56MHz ISO 14443A/B) | |
| Laser scanner | OPTION | |
| C-MOS imager | 3.0M pixels AF | |
| External Interface | RS232;SPI;print | |
| Protection class | IP54 | |
| Drop resistance level | 1.8m | |
| Audio | Handfree | Yes |
| StereoBlueTooth earphone | Yes | |
| Ringtone | support 64-chord MIDI, MP3, WMA, WAV | |
| Playback | support MIDI, MP3, WMA, WAV, AMR | |
| Camera Function | Camera | 3.0 Mega CMOS AF |
| Size |
160*120, 320*240,640*480,1280*960,1600*1200, 2048*1536 |
|
| Zoom | Digital Zoom | |
| Video | Support still image and video capture | |
| Speaker | support handfree | |
| Network Led | red/green/yellow | |
| Keypad | Front | Number key, Function key |
| Side | Volume up, Volume down,camera | |
| Interface | Mini-USB connector | USB2.0 connection and power charging |
| SIM card slot | Yes | |
| Audio Jack | NO | |
| Battery | Type | rechargeable Li-ion battery 3000mAh |
| Standby Time | 500hours | |
| Calls Time | Up to 6hours | |
| Charging Time | 4 hours | |
| Physical Characteristics | Dimension | 149*72*28mm |
| Weight | TBC | |
| Key Software | ||
| Operating System | Windows Mobile 6.1/6.5 professional / WINCE6.0 | |
| KVM | JAVA MIDP 2.0 | |
| Default language | English | |
| Package Contents | ||
| Standard Packaging: Main Unit*1pc, Charger*1pc, USB Cable*1pc, battery*1pc | ||
Mainly used in telecommunications, GPS, taking pictures , Barcode scanner , RFID Reader and so on ;
Competitive Advantage :
1. We have our own manufacture factory in Beijing ;
2. Scientific management, advanced production equipment;
3. Own r&d team and technical personnel;
4. Excellent after-sales service and technical support;
